FEATURES
- 20 MHz sine / 10 MHz square & pulse — dual-channel output with 1 µHz frequency resolution, 20 Vpp maximum amplitude (high-Z), full amplitude maintained at maximum frequency.
- 16-bit vertical resolution — 65,536 amplitude levels. 4× the resolution of the 14-bit DACs typical at this price point, reducing quantization noise and improving signal purity.
- 200 MSa/s sample rate — 10 sample points per cycle at maximum sine frequency, supporting accurate waveform reconstruction without staircasing.
- 200 built-in arbitrary waveforms — comprehensive library of standard, mathematical, medical, and engineering waveform shapes. 4 kpts arbitrary waveform length for custom shapes.
- 7 modulation types — AM, FM, PM, ASK, FSK, PSK, PWM — internal and external source. Adds digital-modulation capability beyond what the UTG900E Classic-Series provides.
- Pulse burst function — three modes (N-cycle, gated, infinite) with internal or external trigger, rising or falling edge.
- Built-in 7-digit frequency counter — 100 mHz to 200 MHz input range.
- Low jitter, low harmonic distortion — 150 ps typical pulse-wave jitter; THD < 0.2% (DC to 20 kHz, 1 Vpp).
- USB-Device and USB-Host — PC SCPI control plus direct thumb-drive arbitrary waveform upload, without computer-tethering.
